Chovyting CW-1100BS5+AP High Speed Calendar Bag Making Machine

Chovyting CW-1100BS5+AP High Speed Calendar Bag Making Machine

Description

High speed calendar making machine has the following characteristics:

1. For bottom sealing bag production as well as calendar bag making.

2. With bag blocked device,performation device and punch device for different bag making requirements.

3. Fit for 5-lines blank and printed calendar bag making.

Optional: Gusset system(1-5lines)

What is a Calendar Making Machine?

A machine designed to create calendar bags, covers, and related packaging materials, often used for promotional or personal purposes.

What types of materials can be used with a Calendar Bag Making Machine?

Most machines work with plastic films, laminates, paper, or other flexible packaging materials suitable for creating durable calendar bags.

Is the Calendar Making Machine fully automatic?

Yes, many modern calendar making machines are fully automatic, reducing labor costs and improving efficiency.

Can the Calendar Bag Making Machine handle custom designs?

Yes, many machines are equipped with the ability to produce custom designs based on specifications provided by the user.

How does the Automatic Calendar Cover Making Machine differ from manual machines?

Automatic machines offer greater efficiency, precision, and speed compared to manual machines, requiring less human intervention.

Can the Calendar Bag Making Machine handle high-volume production?

Yes, most modern machines are capable of high-volume production, making them ideal for bulk manufacturing.

Is training required to operate a Calendar Making Machine?

Yes, operators typically need to be trained on machine setup, operation, and maintenance to ensure optimal performance.

What is the maintenance schedule for a Calendar Bag Making Machine?

Regular maintenance is recommended, including cleaning, lubrication, and inspecting the sealing and cutting components.

Specifications

ManufacturerChovyting
ModelCW-1100BS5+AP
ConditionNew
Stock NumberCW-1000BS5+AP
Bag length250-700mm
Bag sample without punch (with block function)bag sample after punch & perforation line
Dimension of machine8800x2030x2050mm
Film unwind diameter1000mm
Film unwind width900mm
Line speed85m/min
No.of tracks(max)5lines
Production speed180 pcs/min
Thickness of film0.01-0.04mm
Total power17.6KW
Weight of machine2660kg
Servo motorYaskawa
IntverterYaskawa
PhotocellDatalogic
PLC controlPanasonic
Machine dimension(lxwxh]8800x2030x2050mm
