CW-700IEB Servo Driven FFS heavy duty polythene tube film embossing gusseting machine
CW-700IEB Servo Driven FFS heavy duty polythene tube film embossing gusseting machine
Description
The Form, Fill, and Seal (FFS) packaging film designed to be reliable, simple, and cost effective, while offering manycustomization options.(FFS) packaging film offers advantages over premade bagging such as increased production speed, reduced per-bag cost, and increased flexibility in finished bag size.It also has the feature of preventing slipping in the pallet arrangement with its embossed structure.FFS is an ideal packaging solution for many different industries including petrochemical and plastic resins, agricultural, chemical, biomass, industrial manufacturing, pet food and livestock feed, lawn and garden. Products that may be packaged by these machines include resin pellets, wood pellets, salt, fertilizer, rocks and stone, chemicals, powders, spices and powders, dried foods, cement and slurries, and granular products.
Specifications
| Manufacturer | Chovyting |
| Model | CW-700IEB |
| Condition | New |
| Stock Number | CW-600IEB |
| Applicable materials | HDPE、LDPE |
| Diameter of jumbo roll | 1000mm |
| Diameter of rewind | 1500mm |
| Material thickness | 0.04mm ~ 0,3mm |
| Max depth of side gusset | 40-100mm |
| Production speed | 150m/min |
| Rewind mismatch distance | 2-100mm |
| Total power | 12.7KW |
| Weight of machine | 3500kg |
| Width of jumbo roll | 700mm |
| Machine dimension(lxwxh] | 8,5m x 1,45m x 2,7m |
