CW-400V2 Fully Automatic Super High Speed T-shirt Bag Making Machine
CW-400V2 Fully Automatic Super High Speed T-shirt Bag Making Machine
or
Call +32 53 67 07 89
Specifications
| Manufacturer | Chovyting |
| Model | CW-400V2 |
| Condition | New |
| Subcategories | T-shirt bags |
| Bag length | 370-700mm |
| Bag width | 400mm×2Lines |
| Dimension of machine | 8000×1850×1800mm |
| Line speed | 125M/min |
| Machine weight | 3100kg |
| Production speed | 250pcs×2Lines |
| Sealing and cutting knife device 1. sealing knife with 90 degree “turnover” device, which easy to clean the knife, which is better to keep the maintenance easy 2. the whole set of bags has design of swaying, no paste between two bags mouth (italy design) 3. fully automatic tacking of whole set and levelling stack design | Hydraulic air cylinder punch (photo have 3 punch as reference! CW-400V2 only two punch) 1. With 5 tons hydraulic air cylinder punch from Taiwan 2. the motor of clip for clamp the bag is Ac inverter motor control 1.5KW 3. Automatic collect bags and finish stack bags with double fold device |
| Total power | 18.5kw |
| Unwinder 1. unwinder adopts air cylinder automatic load design. max.diameter of the unwinder is 700mm. 2. adopts ac frequency motor driving constant tension control, feeding speed is according to the producing speed. 3. unwinding shaft adopts heavy-chainair shaft. 4. unwinder part has the epc and automatic tension control. 5. automatic stop design when rolls film finish or damage. | Automatic EPC control 1. This device special for this high speed model 2. When roll film feeding so fast that the film will move little left and right, with this EPC device to be control the film feeding corrected to the right position 3. This EPC system will enhance the productivity of machine 4. One set EPC system to control two lines. |
