CW-500ZD Fully Automatic Bottom Seal Soft Loop Handle Bag Making Machine
CW-500ZD Fully Automatic Bottom Seal Soft Loop Handle Bag Making Machine
or
Call +32 53 67 07 89
Specifications
| Manufacturer | Chovyting |
| Condition | New |
| Subcategories | Bottom seal bags |
| Air compressor (not included) | 7HP |
| Length of bag-making | 250-600mm |
| Machine dimension | 6500*2000*1900mm |
| Machine weight | 2000kg |
| Photocell sensor device 1. vertical, horizontal moving independence2. zero malfunction photocell use datalogic from italy3. rotary-photocell reflected roller4. three-side location by photocell, servo motor, plc | soft Loop handle sealing applicator 1. Double layer unwinding bracket2. Special ramp pulling over-turn soft loop handle3. Semi-motor drives the soft loop handle device forward or backward. |
| Speed of bag-making | 60 pcs/min |
| The dimension of handle film | 0.2*30*360mm |
| Total power | 8.5kw |
| Type | CW-500ZD |
| Unwinder 1. jumbo roll automatic lifting device with air cylinder2. plug feeding shaft and air shaft3. automatic tension control4.single photocell control epc | V type sealing device (K sealing device) 1. Pneumatic control up-down V type sealer2. Multi-position distance adjust3. High temperature cloth is rewinded fast. |
| Width of bag-making | 200-500mm |
